It comes standard without brakes but can be added.

Boats from 30'-33'
Load capacity of 18,200 lbs.
Tire size ST235 / 80R16E radials on eight-bolt galvanized wheels
Three 7,000 lb. galvanized steel axles with torsion suspension
Maintenance-free sealed bearing system (Six-year warranty)
Disc brakes on all wheels (five-year warranty)
Stainless steel fasteners
10" aluminum I-beam mainframe and aluminum cross members
Lunette Ring Surge Brake Actuator with backup solenoid/ manual lockout
3,500 lb. manual two-speed winch with strap
Six adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 30'-33'
- Load capacity of 17,200 lbs.
- Tire size ST235 / 80R16E radials on eight-bolt galvanized wheels
- Three 7,000 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 9" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" surge brake coupler with backup solenoid and manual lockout
- 3,500 lb. manual two-speed winch with strap
- Six adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 30'-33
- Load capacity of 15,600 lbs.
- Tire size ST235/80R16E radials on six-bolt galvanized wheels
- Three 6,000 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 8" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" Surge Brake Actuator with backup solenoid and manual lockout
- 3,500 lb. manual two-speed winch with strap
- Six adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 25'-28'
- Load capacity of 13,000 lbs.
- Tire size ST225 / 75R15E radials on six-bolt galvanized wheels
- Three 6,000 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Surge Disc brakes on all wheels
- Stainless steel fasteners
- 7.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" surge brake coupler with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 28'-30'
- Load capacity of 13,000 lbs.
- Tire size ST225 / 75R15E radials on six-bolt galvanized wheels
- Three 6,000 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Surge disc brakes on all wheels
- Stainless steel fasteners
- 7.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" surge brake coupler with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 26'-28
- Load capacity of 9,000 lbs.
- Tire size ST215 /75R14C radials on five-bolt galvanized wheels
- Three 3,750 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 7.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 26'-28
- Load capacity of 10,000 lbs.
- Tire size ST235 / 80R16E radials on six-bolt galvanized wheels
- Two 6,000 lb. galvanized steel axles with torsion suspension
- Maintenance-free sealed bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 7.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 24'-26'
- Load capacity of 8,500 lbs.
- Tire size ST225 / 75R15E radials on six-bolt galvanized wheels
- Disc brakes on all wheels
- Maintenance-free Oil-bah bearing system (Six-year warranty)
-Two 6,000 lb. Galvanized steel axles with torsion suspension
- Stainless steel fasteners
- 7.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 22'-24'
- Load capacity of 7,000 lbs.
- Tire size ST225 / 75R15E radials on six-bolt galvanized wheels
- Surge disc brakes on all wheels
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Two 6,000 lb. Galvanized steel axles with torsion suspension
- Stainless steel fasteners
- 6.5" aluminum I-beam mainframe and aluminum cross members
- 2 5/16" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 22'-24'
- Load capacity of 6,000 lbs.
- Tire size 205 / 75R14C radials on five-bolt galvanized wheels
- Two 3,750 lb. Galvanized steel axles with torsion suspension
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 6.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- Four adjustable pivoting carpeted bunks and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 20'-22'
- Load capacity of 5,000 lbs.
- Tire size 205 / 75R14C radials on five-bolt galvanized wheels
- Two 3,750 lb. Galvanized steel axles with torsion suspension
- Disc brakes on all wheels
- Maintenance-free oil-bath bearing system (Six-year warranty)
- Stainless steel fasteners
- 5.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 3,200 lb. manual two-speed winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 18'-20'
- Load capacity of 4,000 lbs.
- Tire size ST225 / 75R15E radials on six-bolt galvanized wheels
- One 6,000 lb. Galvanized steel axle with torsion suspension
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 5.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 1,800 lb. single-speed manual winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 20'-22'
- Load capacity of 4,000 lbs.
- Tire size ST225 / 75R15D radials on six-bolt galvanized wheels
- One 6,000 lb. Galvanized steel axle with torsion suspension
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 5.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 1,800 lb. single-speed manual winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 15'-18'
- Load capacity of 3,000 lbs.
- Tire size ST205 / 75R15C radials on five-bolt galvanized wheels
- One 3,750 lb. Galvanized steel axle with torsion suspension
- Disc brakes on all wheels
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Stainless steel fasteners
- 4.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 1,800 lb. single-speed manual winch with strap
-4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

- Boats from 18'-20'
- Load capacity of 3,000 lbs.
- Tire size ST205 / 75R15C radials on five-bolt galvanized wheels
- One 3,750 lb. Galvanized steel axle with torsion suspension
- Disc brakes on all wheels
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Stainless steel fasteners
- 4.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
-1,800 lb. single-speed manual winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 15'-18'
- Load capacity of 2,500 lbs.
- Tire size ST205 / 75R14C radials on five-bolt galvanized wheels
- One 3,750 lb. Galvanized steel axle with torsion suspension
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Stainless steel fasteners
- 4.5" aluminum I-beam main frame and aluminum cross members
- 2" Bumper Pull Coupler
- 1,800 lb. Single-speed manual winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)

It comes standard without brakes but can be added.

- Boats from 18'-20'
- Load capacity of 4,000 lbs.
- Tire size ST225 / 75R15D radials on six-bolt galvanized wheels
- One 3750 lb. Galvanized steel axle with torsion suspension
- Maintenance-free Oil-bath bearing system (Six-year warranty)
- Disc brakes on all wheels
- Stainless steel fasteners
- 5.5" aluminum I-beam mainframe and aluminum cross members
- 2" Surge Brake Actuator with backup solenoid and manual lockout
- 1,800 lb. Single-speed manual winch with strap
- 4 Bunks in total: 2 long and 2 short and adjustable winch Post/Bracket
- Sealed marine quality LED lighting (lifetime warranty)
